Light Source:

Light Source:   288 colour Luxeon LEDs
Fixed Output:   0 - 4,500lm (Programmable)
Fixture Efficacy:   100 - 120 lm/W
(dependent on colour temperature & dim level)
4,500 lumens from 37W
Fixture Power:   5 - 45W (Programmable)
Operating Life:   > 60,000 hours L90
Projected L70 > 250k hrs
Colour Temp.:   White 2500 - 6000K nom.
Colour Rendering:   > 95 CRI
R9 > 90
TM-30: Rf 90, Rg 100
Cyanosis Index:   0.98 @ 4000K
Flicker:   Nil
Output:   No UV or IR
Dimming:   0 - 100%

Power Supply:

Input Voltage:   24V DC
Input Power:    < 65W (2.7A @ 24V)
Power Supply:   85-305VAC to 24V 100W
MTBF:   700,000 hrs @ 25°C

Environmental:

Ambient Temp.:   -20°C to 50°C
Operating Temp.:   50°C at 25°C ambient

Mechanical:

Dimensions:   1195mm (length) x 295mm (width) x 95mm (height)
Weight:   approx. 6.2kg
