The Panelux Junior is an ultra high efficiency, fully sealed, rugged LED light fixture with autonomous integrated intelligence designed for extreme environments.

Control:

Embedded within each fixture is an autonomous controller that interacts with nearby fittings to optimise power savings while maintaining excellent illumination.

No additional control system is required.

Optional Sensing of:

  • Forklifts – RF Beacon.
  • General Motion - Microwave.
  • Ambient Temperature.
  • Ambient Light.
  • Hazardous Vapour.

Applications:

Mechanical:

The housing is fully corrosion resistant in Aluminium & Stainless Steel with a design life of 20 years.
Body material: Aluminium
Length / Width: 389 x 389mm
Weight: Approx 2.5kg

Highly Efficient

5,600 lumens from 40W for 140lm/W fixture efficacy.

Extreme Operating Life

> 60,000 hrs at 90% lumen maintenance with MTBF of 3,500,000 hrs at 25°C.

Extereme Operating Conditions

Runs down to -40°C with instant start.

Plug and Play

Self contained, self configuring network. No supporting cabling or infrastructure required. Provides data transport for additional sensors.

Forklift proximity detection

Senses forklift proximity and illuminates a working area around the forklift. Static or fully dynamic (under motion).

Occupancy Sensing

Integrated microwave sensor option allows adaptive lighting strategies and occupancy monitoring.

Daylight Harvesting

System wide detection of ambient light conditions reduces amount of “fill in” lighting required.

Task Tuning

Individual (or groups) of luminaires can maintain different target light levels to suit tasks being perform in their areas.

Zone Control

Luminaires can be grouped into zones for grouped control strategies (for example, loading bay vs aisle racking)

Addressable

Luminaries are uniquely addressable for unique control strategies (or sensor monitoring) independent of electrical wiring.

Continuous Dimming

Light level from 0-100% in 200+ steps for smooth lighting transitions. Ramp rates fully programmable.

Safe

No glass, mercury, UV or IR. No hazardous waste – recyclable.

Future Proof

Meets or exceeds DesignLights Consortium Intelligent Controls requirements 2016

Local Support

Designed and manufactured in New Zealand

Light Source
Light Source:   240 x Luxeon LED
Light Output:   5,600 lm nominal
LED Efficacy:   188 lm/W nominal
Lamp Power:   34W
Operating Life:   > 60,000 hrs L90
Projected L70 > 250k hrs
Colour Temp:   White 5000K nom.
Colour Rendering:   80 CRI
Output:   No UV or IR
Dimming:   0-100%

Power Supply
Power Supply:   Integrated within fitting
Power Factor:   98% throughout dimming
Supply Efficiency:   ~98%
Input Power:   40W (36.8W @ 24V AC)
Input Voltage:   240V AC (or 24V AC/DC)
THD:   <20%
MTBF:   3,500,000 hrs @ 25°C
Connector:   IP68 LTW Type A

Environmental
Surge Protection:   Varistor 1.2kA 28J
Ambient Temp:   -40°C to 50°C
Operating Temp:   52°C at 25°C ambient
Fixture Efficacy:   140 lm/W Typical
Rating:   IP67
